JHSCX-20 Acoustic Infrared Integrated Tester
The acoustic sensor array is used to measure the sound field distribution within a certain range and locate the sound source in real time
Visualize sound sources in the form of sonograms, making sound visible to the human eye
Extensible access to infrared temperature measurement imaging module to achieve comparison between acoustic imaging and infrared temperature measurement imaging
acoustic parameters | |
acoustic measurement | 128 low-noise MEMS microphones, sound visualization |
sonogram perspective | 70° |
dynamic range | > 120dB |
broadband | 2kHZ-65kHz, adjustable range |
sonogram frame rate | 25FPS |
Measuring distance | 0.3 meters to 130 meters |
function type | Electrical intelligence, mechanical vibration, gas leakage |
Infrared parameters | |
infrared pixel | 640*512 |
Field of view | 13 ° * 10 °, focal length 19mm |
Range and error | -20 ℃~ 500 ℃, divided, ± 2 ℃ or ± 2% |
Related recommendations
JHRX series, infrared thermal imaging cameras
Expert-level native analysis capabilities assist in diagnosing equipment status
JHYQ-1 Rapid Detector for Dissolved Gas Acetylene in Oil
